Products DescriptionTypeASA Synthetic Resin Roof TileTotal Width880mm,1050mmEffective Width8oomm,960mmLengthCustomized(must be accorded to the times of 219mm)Thickness2.0mm±0.12.5mm±0.13.0mm±0.1Weight4.0±0.1(kg/m2)5.0±0.1(kg/m2)6.0±0.1(kg/m2)Wave Distance160(mm)Wave Hei......
|
Type |
ASA Synthetic Resin Roof Tile |
||
|
Total Width |
880mm,1050mm |
||
|
Effective Width |
8oomm,960mm |
||
|
Length |
Customized(must be accorded to the times of 219mm) |
||
|
Thickness |
2.0mm±0.1 |
2.5mm±0.1 |
3.0mm±0.1 |
|
Weight |
4.0±0.1(kg/m2) |
5.0±0.1(kg/m2) |
6.0±0.1(kg/m2) |
|
Wave Distance |
160(mm) |
||
|
Wave Height |
30(mm) |
||
|
Pitch |
219(mm) |
||
|
Container Loading Capacity |
Thickness(mm) |
SQ.M./20 FCL(28 tons) |
SQ.M./40 FCL |
|
|
².0 |
6500 |
6500 |
|
|
2.5 |
5500 |
5500 |
|
|
3.0 |
4500 |
4500 |
